The Allen & Heath Qu-7 is the largest model in the latest Qu series of professional digital mixing consoles, delivering extensive local I/O, advanced 96kHz processing, comprehensive multitrack recording, and flexible expansion capabilities for demanding live sound, theatre, broadcast, corporate AV, and house-of-worship applications. Powered by Allen & Heath’s XCVI FPGA engine, the Qu-7 provides 38-input mixing capacity, 33 motorised faders, 32 recallable preamps, DEEP Processing support, and seamless integration with the Everything I/O ecosystem, making it an ideal solution for engineers requiring maximum control and connectivity in a compact digital console.
Key features
- 38-input / 24-output digital mixer
- 96kHz XCVI FPGA processing engine
- 32 recallable XLR/TRS combo mic-line preamps
- 33 motorised 100mm faders
- 7" capacitive touchscreen interface
- 6 stereo FX engines with dedicated returns
- 32×32 USB-C audio interface
- 32-channel SD card multitrack recording and playback
- 128×128 SLink intelligent expansion port
- Automatic Microphone Mixer (AMM)
- Gain Assistant and Feedback Assistant
- DEEP Processing ready
- Remote control via Windows, macOS, iOS and Android applications
Overview
| Type | Digital Mixing Console |
| Mix Capacity | 38 Inputs to Mix (32 Mono/Linkable + 3 Stereo) |
| Mic Preamps | 32 Recallable Mic/Line Preamps |
| Processing Engine | 96kHz XCVI FPGA Core |
| Display | 7" Capacitive Touchscreen |
| Faders | 33 × 100mm Motorised Faders |
| Layers | 4 Customisable Fader Layers |
| Buses | 12 Mixes (6 Mono/Linkable + 6 Stereo) |
| Matrix Outputs | 4 Mono/Linkable Matrix Mixes |
| FX Engines | 6 Internal Stereo Multi-FX Engines |
| USB Interface | 32×32 USB-C Audio Interface |
| SD Recording | 16×16 @ 96kHz or 32×32 @ 48kHz |
| Expansion | 128×128 SLink Expansion Port |
| Analogue Inputs | 32 XLR/TRS Combo Inputs + 2 Stereo Inputs + Talkback |
| Analogue Outputs | 20 XLR Outputs + 2 TRS Outputs |
| Digital Outputs | AES3 Stereo Digital Output |
| Networking | RJ45 Ethernet Control Port |
| SoftKeys | 8 User-Assignable SoftKeys |
| Dimensions | 804 × 500 × 214 mm |
| Weight | Approximately 17 kg |
Included Content
- Qu-7 digital mixer
- 32×32 USB-C audio interface
- SD card multitrack recording and playback system
- SLink expansion connectivity
- Power cable
- Qu-MixPad and Qu4You remote-control software
Creative Tools
- Six stereo FX engines featuring reverb, delay, chorus, flanger and modulation effects
- 32-channel Automatic Microphone Mixer (AMM)
- Gain Assistant for automatic input gain optimisation
- Feedback Assistant with automatic suppression filters
- DEEP Processing compatibility with premium Allen & Heath processor models
- 32×32 USB multitrack recording and DAW integration
- SD card multitrack recording without a computer
- Customisable fader layers and assignable SoftKeys
- SLink connectivity for remote stageboxes and system expansion
- Comprehensive dynamics, EQ and processing on every input and mix bus
Ideal For
- Professional live sound engineers
- Large houses of worship
- Theatres and performing arts venues
- Corporate AV and conference facilities
- Broadcast and streaming production
- Touring productions and rental companies
- Recording and rehearsal studios
- Users requiring maximum local I/O in the Qu range
- Installations needing flexible expansion through the Everything I/O ecosystem
