Allen & Heath SQ7+
€5.599,00
Pāriet uz produkta informāciju
Ir pieejams
Allen & Heath SQ7+
Ražotājs: Allen & Heath
€5.599,00
Jautājumi?
Zvani / WhatsApp
+37120273545
Raksti uz
hello@defset.eu
The Allen & Heath SQ7+ is the flagship model in the SQ+ Series, offering professional 48-channel digital mixing with extensive hands-on control for live sound, touring, theatres, broadcast, houses of worship, corporate AV and recording applications. Powered by Allen & Heath's renowned 96kHz XCVI FPGA engine, the SQ7+ features 33 motorised faders, a new 9-inch capacitive touchscreen, enhanced processing power, four dedicated RackUltra FX engines, expanded DEEP Processing support and flexible networking for large-scale productions.
Key features
- 48 input channels with 96kHz XCVI FPGA processing
- 44-bus digital mixing architecture
- 32 recallable microphone preamps
- 33 motorised 100mm faders
- 9" capacitive touchscreen with redesigned dark GUI
- 16 assignable SoftKeys
- 8 assignable SoftRotaries with displays
- 8 RackExtra FX engines
- 4 dedicated RackUltra FX engines
- 32×32 USB audio interface
- SQ-Drive multitrack USB recording
- 128×128 Intelligent SLink expansion
- 64×64 option card slot for Dante, Waves, MADI or SLink
- Next-generation DEEP Processing ready
- Automatic Microphone Mixing (AMM)
Overview
| Type | Professional Digital Mixing Console |
| Mix Capacity | 48 Input Channels |
| Processing Engine | 96kHz XCVI FPGA Core |
| Mix Buses | 44 Total Buses |
| Mic Preamps | 32 XLR Mic/Line Inputs |
| Stereo Inputs | 3 Stereo Line Inputs |
| Local Outputs | 16 XLR Outputs + 2 TRS Outputs |
| Digital Output | AES3 Stereo Output |
| Faders | 33 × 100mm Motorised Faders (32+1 Master) |
| Layers | 6 Assignable Layers |
| Touchscreen | 9" Capacitive Colour Display |
| SoftKeys | 16 Assignable SoftKeys |
| SoftRotaries | 8 Assignable SoftRotaries |
| FX Engines | 8 RackExtra FX + 4 RackUltra FX Engines |
| USB Interface | 32×32 USB-B Audio Interface (48/96kHz) |
| USB Recording | SQ-Drive: 16 Channels @ 96kHz or 32 Channels @ 48kHz |
| Networking | 128×128 SLink + 64×64 Expansion Card Slot |
| Expansion | Compatible with DX, GX, AR, AB and Everything I/O Stageboxes |
| Latency | Less than 0.7 ms |
| Dimensions | 804 × 514 × 198 mm |
| Weight | Approximately 17.8 kg |
Included Content
- SQ7+ digital mixer
- 32×32 USB audio interface
- SQ-Drive multitrack recording system
- 128×128 Intelligent SLink connectivity
- Internal universal power supply
- IEC power cable
- SQ MixPad, SQ4You and SQ Control software support
Creative Tools
- 96kHz XCVI FPGA processing with ultra-low latency
- 33 motorised faders for maximum hands-on mixing control
- Four dedicated RackUltra FX engines for premium reverbs, vocal processing, pitch effects and saturation
- Eight RackExtra FX processors with dedicated stereo returns
- Next-generation DEEP Processing with latency-free analogue hardware emulations
- Two independent 24-channel Automatic Microphone Mixers or one 48-channel AMM
- 32×32 USB interface for recording, streaming and virtual soundcheck
- SQ-Drive direct multitrack recording to USB storage
- 128×128 SLink connectivity for Everything I/O stageboxes and personal monitoring systems
- 64×64 expansion slot supporting Dante, Waves, MADI and additional SLink cards
- Remote operation via Windows, macOS, iOS and Android applications
Ideal For
- Professional live sound engineers
- Touring productions
- Broadcast and streaming facilities
- Theatres and performing arts venues
- Houses of worship
- Corporate AV installations
- Recording studios
- Rental and production companies
- Users requiring maximum physical control with premium 96kHz digital mixing and advanced effects processing
