HK Audio LINEAR 5 MKII 115 Sub A

HK Audio LINEAR 5 MKII 115 Sub A

By HK Audio
€1.439,00
In stock

The LINEAR 5 MK2 115 Sub A is a compact, high‑performance active bass‑reflex subwoofer designed to deliver punchy, defined low‑frequency reinforcement for professional sound systems. Its 15‑inch woofer provides tight, controlled bass that extends into the lowest registers, forming a solid foundation for LINEAR 5 MK2 full‑range tops. With selectable cardioid presets, stereo preamplifiers for easy 2.1 setups, and a robust birch plywood/MDF enclosure, it is built for demanding live sound, rental, and installation environments.

Key features

System type Active bass‑reflex subwoofer
Driver 15" woofer with 3" voice coil
Amplifier power 1200 W Class‑D
Max SPL 130 dB peak
Frequency range 44 Hz – 100 Hz (‑6 dB)
DSP functions 10‑band EQ, LPF, polarity, level, delay, limiter, mute
Filter presets Front, Cardioid 1:1 vertical, Cardioid 1:1 horizontal, Remote
Inputs/Outputs 2× XLR/jack combo, 2× XLR thru, 1× XLR DSP out, Ethernet
Cabinet construction Birch plywood/MDF with steel grille
Mounting options M20 stand flange
Dimensions (W×H×D) 480 × 535 × 675 mm
Weight 32.9 kg

Overview

The LINEAR 5 MK2 115 Sub A is engineered to deliver dry, precise, and powerful bass performance suitable for a wide range of professional applications. Its compact form factor makes transport and setup easy, while the selectable cardioid modes provide effective rear‑attenuation of low frequencies—ideal for stages, indoor venues, and noise‑sensitive environments. The integrated stereo preamplifiers simplify 2.1 system configurations, allowing quick deployment with full‑range tops. The rugged birch multiplex cabinet and anticorrosive steel grille ensure long‑term durability, even under intensive touring conditions.

Included Accessories

  • Power cable
  • User documentation

Included Software

  • Built‑in DSP with 10‑band EQ and selectable cardioid presets
  • Network‑enabled remote control functions (via internal DSP)
